White Planter 8500 Series Service Manual

Covers: White Planter 8516 / 8523 / 8524 / 8531 (S/N HS and Later)
Type: Service Manual
Language: English
Pages: 731
Format: PDF
File size: 126mb
Features: Bookmarked, searchable, printable
Compatibility: Windows/Mac/Tablet/Smartphone

The White Planter 8500 service manual covers service, repair, testing and troubleshooting procedures for your seeder/planter. It is the go-to reference guide professional and DIY mechanics who need in-depth OEM information when performing service work. This is the latest digital edition dated August 2009 with over 700 pages.

A download link for the high resolution PDF manual will be emailed to you immediately — no shipping wait. It can be viewed on your computer, tablet, or smartphone whether you’re in the shop or in the field. A bookmarks panel and clickable links in the table of contents make it easy to quickly navigate chapters and sub-chapters in the manual.

Contents:

• General Information
• Safety
• Specifications
• Installation Instructions
• Field Operations and Adjustments
• Gauge Wheels
• Closing Wheels
• Row Unit Linkage
• Down Pressure Springs
• Row Unit Drivers
• Chemical Attachments
• Seed Meters
• Roller Chains and Sprockets
• Hydraulic Drive
• Drive Shafts
• Air System
• Hydraulic Schematics
• Hydraulic Fluid, Filter and Hoses
• PTO Pump
• Hydraulic Motors
• Hydraulic Oil Cooler
• Hydraulic Cylinders
• Hydraulic Valves
• Light Harness
• Marker, Fold and Lift Harness
• Seed Sensor and Module Harness
• Point Row Clutch Harness
• Lift Wheels
• Wing Mounting
• Tongue and Hitch
• Marker Arm
• CFS Platform and Ladder
• Troubleshooting
  • Electro-Hydraulic
  • Planter
  • ISOBus Controller
• GTA Console I / II Schematics
• Consoles and Monitors
• Software Upgrade Procedure
• SM-4000 Seed Monitor

Please note this manual is sold in downloadable PDF format. If you have any questions about this product, please contact us and reference the product name or SKU.
